【Technical Parameters】

1．Pressure Sensor Range: 0-500 kPa;

2．Air and Liquid Storage Tanks: Stainless steel material;

3．Adjustable Time Range: 1s～60min, Time Accuracy: 0.2s;

4．Five Independent Test Stations: Each outlet is independently controlled without mutual interference, and the fixtures at the outlets are adjustable;

5．Display Function: Equipped with a liquid crystal display (LCD) supporting Chinese menu, including nominal specification, set load, print setting, test, up, down, time, and calibration. The menu on the LCD is controlled by a keyboard and touch panel, with on-board printing of test results.

【Accessories List】

1．Standard Accessories;

2．Oil-Free Air Compressor: 1.5kW, 30L, Single-Phase.
